Problem

Problems with the paper feed

The paper is not fed in

Paper jam (fanfold paper)

Corrective action
1 Check that the display shows the correct paperway, if necessa-
ry select the correct paperway (single sheet or fanfold) with the
key Park. See Changing the paper
to use optional paper types, make sure they are correctly instal-
led.
2 Make sure that the paper guide is correctly adjusted at the side.
3 When using single sheets, push the paper fully into the paper
feed.
When having torn off the fanfold paper and after
switching over from fanfold paper to single sheets,
the fanfold paper moves to the park position.
4 Check that the fanfold paper is in the park position when you
insert a single sheet. This means the fanfold paper should not
be loaded (pulled in). To check this, raise the guide of the single
sheet feeder.
If necessary, drive the remaining paper manually to
the park position with the
1 Open the top cover. If a paper jam should occur, then remove
the jammed paper by tearing it off at the tear off edge (the tear
off edge is located at the outfeed for the fanfold paper).
2 Press the key to transport the paper backwards.
3 You may support the paper return feed by cautiously pulling the
paper in the correct direction.
Before you replace the fanfold paper, refer to the instructions in the
section Loading paper, (page 30).
You should pay special attention to the following points:
Insert the paper straight.
After inserting the paper, close the tractors.
Adjust the tractors, the paper should be positioned in the trac-
tors straight but without tension.
Adjust the printhead gap to the paper thickness (if AGA=Off).
Set the parameter Head-up to On, see section
printhead gap (Head
Clean upper friction, see section
(page 108).
type, (page 27). If you wish
key.
up), (page 86).
Cleaning the upper
Troubleshooting
Increasing the
friction,
