Remote Controller Bracket - Icom IC-2820H Instruction Manual

• Remote installation
Main unit
• The supplied remote controller bracket and separation cable
can be used for installation.
• Optional OPC-440
MICROPHONE CABLE
available to extend the microphone cable.
• Optional OPC-441
SPEAKER CABLE
able to extend the speaker cable.
Controller
(5.0 m; 16.4 ft) is
(5.0 m; 16.4 ft) is avail-
QUICK REFERENCE GUIDE
D Location
Select a location which can support the weight of the trans-
ceiver and does not interfere with driving. We recommend the
locations shown in the diagram below.
NEVER place the transceiver or remote controller where nor-
mal operation of the vehicle may be hindered or where it
could cause bodily injury.
NEVER place the transceiver or remote controller where air
bag deployment may be obstructed.
DO NOT place the transceiver or remote controller where hot
or cold air blows directly onto it.
AVOID placing the transceiver or remote controller in direct
sunlight.
Controller
Main unit
Main unit
Main unit
II
