16
GPS/GPS-A OPERATION
tRotate [DIAL] to select the desired character.
• Push [Aa](TONE•DTMF) to select the character group from cap-
ital letters or lower case letters.
• Push [1/](M/CALL•MW)
group from numbers or symbols.
• Push [>](M/CALL•MW)
push [<](V/MHz•SCAN) (Left band's) to move the cursor left.
• Push [CLR](DUP/MONI) to clear the selected character.
• Push and hold [CLR](DUP/MONI) for 1 sec. to clear all charac-
ters after the selected character.
y Push [MAIN•BAND] to set the message.
• The cursor disappears.
u Push [F•
] once to return to frequency indication.
129
to select the character
(Right band's)
to move the cursor right;
(Left band's)
D D Receiving a GPS transmission
qWhile in DV mode operation, push [F•
display function guide 3.
w Push [POSI](M/CALL•MW)
the "RX POSITION" screen.
e Push and hold [R-WR](LOW•PRIO) for 1 sec. to store the
received position information.
r Push [F•
] once to return to frequency indication.
Distance between received station and your positions
Direction of received station
✔ For your information!
The position display of a received signal is available only if
the transmitting station is using at least one of the following
sentence formatters; RMC, GGA, or GLL.
] three times to
twice to display
(Left band's)
Frequency
Received call sign indication
