QUICK REFERENCE GUIDE
3. Selecting the operating frequency band
The IC-2820H can use 2 m or 70 cm on either the left or right
band. The operating band can be exchanged between them,
and using the same bands, V/V and U/U, is also possible..
[MAIN•BAND]
[DIAL]
Frequency band initial is displayed.
➥ Push and hold the desired band's (left or right)
[MAIN•BAND] for 1 sec. then rotate the appropriate band's
[DIAL].
• Push [MAIN•BAND] momentarily to return to frequency indica-
tion.
XI
4. Tune the frequency
The tuning dial will allow you to dial in the frequency you want
to use. Pages 17 and 18 will instruct you on how to set the
tuning speed.
Rotate the desired [DIAL].
Using the HM-133
You can directly enter the frequency with the HM-133 keypad
for the main band.
[EXAMPLE]: Setting frequency to 145.3625 MHz.
Push
Push
Push
Push
