D Cloning error
NOTE: DO NOT push any key on the sub-transceiver dur-
ing cloning. This will cause a cloning error.
When the display as below appears, a cloning error has oc-
curred.
In such a case, both transceivers automatically return to the
clone standby condition and cloning must be repeated.
OTHER FUNCTIONS

D Cloning using a personal computer

Data can be cloned to and from a personal computer (Mi-
crosoft ® Windows ® 98/2000/Me/XP) using the optional CS-
D800 and the optional cloning cable
CLONING SOFTWARE
OPC-478U (USB type) or OPC-478 (RS-232 type). Consult
the CS-D800
CLONING SOFTWARE
to RS-232 port
OPC-478
or
OPC-478U
to USB port
12
HELP file for details.
Personal computer
