SPECIFICATIONS AND OPTIONS
I Specifications
D D GENERAL
• Frequency coverage
USA
EXP
* 1 Guaranteed: 144–148 MHz range only.; *
430–440 MHz for the EXP version; *
ranges are inhibited for USA version and not guaranteed.
• Type of emission
• Number of memory channels
• Frequency resolution
• Digital transmission speed
• Voice coding speed
• Operating temperature range
• Frequency stability
• Power supply requirement
• Current drain
(at 13.8 V DC: approx.)
Transmit
Receive
• Antenna connector
• Dimensions
(proj. not included)
• Weight
(approx.)
All stated specifications are subject to change without notice or obligation.
121
:
Rx 118.000–173.995 MHz*
1
230.000–549.995 MHz* 2
810.000–999.990 MHz* 3
Tx 144–148 MHz, 440–450 MHz
Rx 118.000–173.995 MHz* 1
230.000–549.995 MHz* 2
810.000–999.990 MHz
Tx 144–148 MHz, 430–440 MHz
2 Guaranteed: 440–450 MHz range for the USA,
3 824.005 to 848.995 and 869.005 to 893.995 MHz
: FM, GMSK (digital), AM
(Receive only)
: 512 (incl. 10 scan edges and 2 calls)
: 5, 10, 12.5, 15, 20, 25, 30, 50, 100, 200 kHz
: 4.8 kbps
: 2.4 kbps
: –10°C to +60°C; +14˚F to +140˚F
: ±2.5 ppm
(–10°C to +60°C)
: 13.8 V DC ±15%
:
at 55 W (VHF) 12.0 A
at 50 W (UHF) 12.5 A
standby 0.9 A
max. audio 1.1 A
(50 Ω)
: SO-239
: 141(W) × 40(H) × 185.4(D) mm
5 9 ⁄ (W)×1 9 ⁄ (H)×7 5 ⁄ (D) in
16 16 16
: 1.2 kg; 2 lb 10 oz
D D TRANSMITTER
• Modulation system
, FM
, DV (Digital)
• Output power
, • Max. frequency deviation
,
• Spurious emissions
• Microphone connector
D D RECEIVER
• Receive system
• Intermediate frequencies
• Sensitivity
FM: at 12 dB SINAD/AM: at 10 dB S/N
118.000–173.995 MHz
230.000–299.995 MHz
300.000–499.995 MHz
500.000–549.995 MHz
810.000–999.990 MHz
DV (digital) BER 1%
VHF/UHF band
• Squelch sensitivity
• Selectivity
Wide
Narrow
• Spurious and image rejection
• AF output power
(at 13.8 V DC)
• Ext. speaker connectors
:
Variable reactance frequency modulation
GMSK reactance frequency modulation
: VHF 55/15/5 W
UHF 50/15/5 W
: ±5.0 kHz
(FM wide: approx.))
±2.5 kHz
(FM narrow: approx.)
: Less than –60 dB
(600 Ω)
: 8-pin modular jack
: Double-conversion superheterodyne
: 1st: 46.05 MHz, 2nd: 450 kHz
:
Less than 0.18 µV/0.45 µV
Less than 0.32 µV/0.79 µV
Less than 0.22 µV/0.63 µV
Less than 0.32 µV/Not specified
Less than 0.45 µV/Not specified
Less than 0.35 µV
: Less than 0.13 µV
(FM mode only) (threshold)
:
More than 12 kHz/6 dB
Less than 30 kHz/60 dB
More than 6 kHz/6 dB
Less than 20 kHz/60 dB
: More than 60 dB
: More than 2.0 W
at 10% distortion with an
8 Ω load
: 3-conductor 3.5 (d) mm (
(approx.)
(approx.)
")/8 Ω
1
⁄
