z Set the desired repeater's frequency, offset and
SET
shift direction in VFO mode.
B
• Select "DV" mode in advance. (p. 15)
x Set your own call sign.
• See p. 62 for your own call sign programming.
c Set the desired station call sign.
• When making a CQ call
Set the desired repeater's
sign, for the area you want to make a CQ call,
into "UrCALL."
• See p. 64 for station call sign programming.
v Set the repeater's call sign as follows;
a Push [
B(D-OFF)] to enter call sign set mode.
SET
• Push [Y Y ] or [Z Z ] to select "CALL" if necessary.
s Push [
B(D-OFF)] or [
SET
times to select "RPT1 C."
d Push [Y Y ] or [Z Z ] to select the nearest re-
peater's call sign.
f Push [
B(D-OFF)] for 1 sec. to set the call
SET
sign for "RPT1 C."
g Push [
B(D-OFF)] to select "RPT2 C."
SET
h Push [Y Y ] or [Z Z ] to select the gateway re-
peater's
(in the same zone)
• The call sign should have "G" setting as the 8th digit.
• Push [SET•LOCK] or [S.MW•MW] to display last 6-
digit or first 6-digit of the call sign, respectively.
j Push [
B(D-OFF)] for 1 sec. to set the call
SET
sign for "RPT2 C."
k Push [
A(MW)] to exit call sign set mode.
CLR
b Push [PTT] to transmit; release to receive.
(p. 22)
(p. 65)
(pgs. 66, 67)
call
(in a different zone)
C(T-OFF)] several
ENT
call sign.
DIGITAL MODE OPERATION
I Received call sign
When a call in digital voice mode is received, the calling sta-
tion and using repeater call signs being used can be stored
into the received call record. The stored call signs are view-
able in the following manner.
D D Desired call record indication
q Push [SET•LOCK] to enter call sign set mode.
• Rotate [DIAL] to select "CALLS" if necessary.
w Push [SET•LOCK] or [S.MW•MW] several times to select
the received call indication.
• "RXCALL," "RXRPT1," and "RXRPT2" are available for the re-
ceived station, repeater 1 and repeater 2 call signs, respectively.
e To confirm the received call, push [BAND•MODE] to enter
the received call sign indication mode.
• When "RXCALL" is selected in step w, the additional note can
be displayed by pushing [BAND•MODE].
• Push [SET•LOCK] or [S.MW•MW] to display last 6-digit or first
6-digit of the received call sign, respectively.
• Push [BAND•MODE] once or twice to exit the indication mode.
r Push one of [TONE•T-SCAN•BK], [LOW•DUP] or
[MONI•DTMF•EMR] to exit call sign set mode.
