Icom ID-800H Instruction Manual page 74

10
POCKET BEEP AND TONE SQUELCH
D Available tone frequency list
67.0 79.7 94.8 110.9
69.3 82.5 97.4 114.8
71.9 85.4 100.0 118.8
74.4 88.5 103.5 123.0
77.0 91.5 107.2 127.3
NOTE: The transceiver has 50 tone frequencies and con-
sequently their spacing is narrow compared to units having
38 tones. Therefore, some tone frequencies may receive
interference from adjacent tone frequencies.
To prevent interference from adjacent tone frequencies, using
the frequencies as in the following table, is recommended.
• Recommended CTCSS frequencies
67.0 77.0 88.5 100.0
69.3 79.7 91.5 103.5
71.9 82.5 94.8 107.2
74.4 85.4 97.4 110.9
• Recommended DTCS codes
023 065 131 172
025 071 132 174
026 072 134 205
031 073 143 223
032 074 152 226
043 114 155 243
047 115 156 244
051 116 162 245
054 125 165 251
57
131.8 156.7 171.3 186.2 203.5
136.5 159.8 173.8 189.9 206.5
141.3 162.2 177.3 192.8 210.7
146.2 165.5 179.9 196.6 218.1
151.4 167.9 183.5 199.5 225.7
114.8 131.8 151.4 173.8 203.5
118.8 136.5 156.7 179.9 210.7
123.0 141.3 162.2 186.2 218.1
127.3 146.2 167.9 192.8 225.7
261 346 431 532 654
263 351 432 546 662
265 364 445 565 664
271 365 464 606 703
306 371 465 612 712
311 411 466 624 723
315 412 503 627 731
331 413 506 631 732
343 423 516 632 734
D Calling a waiting station using pocket beep
A subaudible tone matched with the station's CTCSS tone fre-
229.1
quency or 3-digit DTCS code with polarity is necessary. Use
233.6
241.8
the tone squelch on the next page or a subaudible tone en-
250.3
coder
(pgs. 23–25)
254.1
233.6
241.8
250.3
743
754
.
