Features

Input and output connectors — All connectors are clearly labeled as either input or
Bandwidth — Bandwidth is a minimum of 375 MHz (-3 dB), fully loaded. This
Digital Sync Validation Processing (DSVP
RS-232/
422
Ethernet
Figure 1-2 — DSVP data display
Rooming — Each Matrix 12800 system can be programmed to group multiple
Triple-Action Switching
1-4 Matrix 12800 Switchers • Introduction
output for easy installation. With the Extron virtualization/control software,
a visual map can be printed for easy representation of the virtual I/Os. This
feature reduces the time required for setup and programming.
high bandwidth allows Extron switchers to switch everything from NTSC
video to high-resolution computer video.
unmanned, remote locations, it is vital to know that sources are active and
switching. The exclusive Extron DSVP confirms that input sources are active
by scanning all sync inputs for active signals. DSVP provides instantaneous
frequency feedback for composite sync or separate horizontal and vertical
sync signals via the RS-232/RS-422 port of the switcher. The frequency
information can be displayed on any control system or in a Windows
control program on a local-area network (LAN) or internet (IP) connection
(figure 1-2).
Signal: PRESENT
Sync Type: H&V
Vertical Freq.: 60 Hz
Horz Freq.: 31.5 kHz
Input Horz. Vert.
01 31.50
02 31.50
03 31.50
04 48.01
05 48.01
06 48.01
07 48.01
08 61.55
09 61.55
10 61.55
11 61.55
12 61.55
• •
• •
• •
outputs to specific "rooms", allowing them to have their own presets. The
system can have up to 32 rooms, each of which can have up to 10 presets.
(RGB delay) — RGB delay blanks the screen when the
™
matrix switcher switches to a new RGB video source. The new sync signals
precede the RGB signals, so there is no noise-filled scramble shown during
the transition. The time delay between the RGB and sync signals is user
adjustable up to five seconds via SIS and Windows program control.
) — In critical environments or
™
Input # 01
MATRIX INPUT STATUS
Input # 01
Signal: PRESENT
Sync Type: H&V
Vertical Freq.: 60 Hz
Horz Freq.: 31.5 kHz
Input # 05
Signal: PRESENT
Sync Type: H&V
Vertical Freq.: 60 Hz
Horz Freq.: 31.5 kHz
Input # 09
Signal: PRESENT
60.00
Sync Type: H&V
Vertical Freq.: 60 Hz
Horz Freq.: 31.5 kHz
60.00
60.00
3rd party control system
67.50
67.50
67.50
67.50
72.00
72.00
72.00
72.00
72.00
•
•
•
Windows-based control program on
LAN or IP connection
® -based
Input # 02 Input # 03 Input # 04
Signal: PRESENT Signal: PRESENT Signal: PRESENT
Sync Type: H&V Sync Type: H&V Sync Type: H&V
Vertical Freq.: 60 Hz Vertical Freq.: 60 Hz Vertical Freq.: 60 Hz
Horz Freq.: 31.5 kHz Horz Freq.: 31.5 kHz Horz Freq.: 31.5 kHz
Input # 06 Input # 07 Input # 08
Signal: PRESENT Signal: PRESENT Signal: PRESENT
Sync Type: H&V Sync Type: H&V Sync Type: H&V
Vertical Freq.: 60 Hz Vertical Freq.: 60 Hz Vertical Freq.: 60 Hz
Horz Freq.: 31.5 kHz Horz Freq.: 31.5 kHz Horz Freq.: 31.5 kHz
Input # 10 Input # 11 Input # 12
Signal: PRESENT Signal: PRESENT Signal: PRESENT
Sync Type: H&V Sync Type: H&V Sync Type: H&V
Vertical Freq.: 60 Hz Vertical Freq.: 60 Hz Vertical Freq.: 60 Hz
Horz Freq.: 31.5 kHz Horz Freq.: 31.5 kHz Horz Freq.: 31.5 kHz
OR
