Connecting as a Telnet client

The Microsoft Telnet utility is available from the DOS prompt. Telnet allows you to
input SIS commands to the switcher from the PC via the Ethernet link and the LAN.
Access the DOS prompt and start Telnet as follows:
1.
2.
3.
4.
Microsoft (R) windows 2000 (TM) Version 5.0 (Build 2195)
Welcome to Microsoft Telnet Client
Telnet Client Build 5.00.99203.1
Escape Character is 'CTRL+]'
Microsoft Telnet>
Figure A-3 — Telnet screen

Telnet tips

It is not the intention of this manual to detail all of the operations and functionality
of Telnet; however, some basic level of understanding is necessary for operating the
switcher via Telnet.

Open

Connect to the switcher using the Open command. Once you are connected to the
switcher, you can enter the SIS commands the same as you would if you were using
the RS-232 link.
Connect to the switcher as follows:
1.
2.
A-4 Matrix 12800 Switchers • Ethernet Connection
On the Windows task bar, click on Start > Run.
At the Open prompt, type command.
Click the OK button.
At the DOS prompt, type telnet and then press [Enter]. The computer returns
a display similar to figure A-3.
At the Telnet prompt, type open {IP address} and then press [Enter].
If the switcher is not password protected, no further prompts are displayed
until you break or disconnect the connection to the switcher.
If the switcher is password protected, Telnet displays the password prompt.
If necessary, at the password prompt, type {password} and then press [Enter].
Connection to the switcher via the Ethernet can be password protected. There
are two levels of password protection: administrator and user. A person
logged on as an administrator has full access to all switching capabilities and
editing functions. Users can select video, audio, or both for output, select test
patterns, set audio or RS-232 mutes, select a blue screen, and view all settings
with the exception of passwords. By default, the switcher ships with both
passwords set to {carriage return}.
Once you are logged in, the switcher returns either Login Administrator or
Login User. No further prompts are displayed until you break or disconnect
the connection to the switcher.
