Part Numbers and Accessories

Matrix 12800 BMEs

Call the Extron S3 Sales & Technical Support Hotline for part numbers. See the rear
cover of this manual for the phone number in your region of the world.

Optional accessories

These items can be ordered separately:
Controllers, connectors, and adapters
FPC 5000 Front Panel Controller
MKP 1200 Remote Keypad
MKP 1000 Remote Keypad
Black
White
WT (water-tight) (black)
WT (white)
MCP 1000M Matrix Control Panel
MCP 1000S Secondary
MKP 2000 Matrix Switcher X-Y Remote Control Panel (black)
MKP 3000 X-Y Remote Control Panel with LCD Display (black)
3.5 mm captive screw connectors, qty. 10
RCAF-BNCM RCA-to-BNC adapter, qty. 10, 50, 100
SVHSM-BNCF 8" S-video-to-BNC adapter, qty. 10
Pin programming jumper, qty. 1

Cables

When using signals with a scanning frequency of 15-125 kHz and running distances
of 100 feet (30 m) or more, use high resolution BNC cables to achieve maximum
performance.
Bulk cable and termination tools
RG6 super high resolution cable
RG6/500 non-plenum 1-conductor, 500' (150 m)
RG6/1000 non-plenum 1-conductor, 1000' (300 m)
RG6P/500 plenum 1-conductor, 500' (150 m)
RG6P/1000 plenum 1-conductor, 1000' (300 m)
MHR mini high resolution cable
MHRVGA/1000 non-plenum 5-conductor, 1000' (300 m)
MHR-2/500 non-plenum 2-conductor, 500' (150 m)
MHR-2P/500 plenum 2-conductor, 500' (150 m)
Matrix 12800 Switchers • Reference Information
Part number
60-503-01
60-528-01
60-239-02
60-239-03
60-239-52
60-239-53
60-298-01
60-298-02
60-682-02
60-708-02
100-457-01
100-229-01, -03,
-04
26-353-01
10-076-10
Part number
22-098-02
22-098-03
22-164-02
22-164-03
Part number
22-024-03
22-123-03
22-129-03
B-5
