All models feature automatic cable equalization for all inputs and automatic re-clocking
for each output. These features reduce the need for additional signal conditioning
equipment by compensating for weak source signals or signal loss when you are using
long input cable assemblies.
The DXP matrix switchers can be operated via the front panel, RS-232 and RS-422 serial
available to operate the DXP switcher remotely.

Features

DXP DVI Pro Series
DXP HDMI Series
DXP DVI Pro and DXP HDMI
All DXP series feature the following:
Inputs and outputs on DVI-I connectors
HDMI signal support
switched with the video but not removed or decoded from the data stream.
Automatic cable equalization for each input to 100 feet (30.4 m) at 1920x1200
Inputs and outputs on HDMI connectors
DVI signal support
removed or decoded from the data stream.
Automatic cable equalization for each input to 100 feet (30.4 m) at 1920x1200
HDMI standard support
formats.
Automatic output re-clocking — Automatic output re-clocking stabilizes data to
correct pair skew and restore signal integrity for improved performance. Signals are
reshaped and the timing is restored to allow for transmission over long cables.
Power for external devices
for external peripheral devices.
EDID reference
any input.
1.65 Gbps digital data rate
standard) and supports carriage of embedded audio, ancillary data, and the ID
information of the data stream.
DDC transmission support — DDC channels are actively buffered, allowing pass-
