Virtualization/Control Software, cont'd

Presets

After you have created all of the ties that are needed for a specific task, the
configuration can be saved as either a global or room preset. The Matrix 12800 can
support up to 64 global presets and up to 10 room presets in each of up to 32 rooms.
To create room presets, you must have already created rooms and assigned outputs
to the rooms, see

Save a preset

1.
2.
3.
4.

Recall or delete a preset

1.
2.
3.
3-16 Matrix 12800 Switchers • Virtualization/Control Software
"Creating rooms within the
On the main screen, click the Rooms drop-down box and select either Global
(All rooms) or one of the rooms that you have already created. If you select
a room, note that the number of ties shown is reduced to reflect only the
outputs that are assigned to that room.
Click the Save as button.
Enter a number in the Save current settings as Preset box (or accept the
number displayed in the box — the program selects the lowest unused preset
number) and click OK.
If desired, enter a name (up to 12 characters) in the next Save current settings
as Preset box and click OK.
On the main screen, click the Presets drop-down box. Scroll down as
necessary and select the desired global or room preset.
Observe that the connections for that preset appear as tentative ties (dashed
lines).
Click the Go or the Delete button to accept or delete the preset.
If you accepted the preset, observe that the broken lines become solid,
indicating that those ties have been created. The preset becomes the current
configuration.
If you deleted the preset, click OK to confirm that you wish to delete the
preset. The current configuration does not change.
system" earlier in this chapter.
