Best Practices; Importing - Lantronix MatchPort b/g Pro Command Reference Manual

settings specified. This can be done on any level, including the root. Special tags in the XML
allow for providing root and enable level passwords so that this can also be done at the
password prompt.
Web browser—Web Manager can be used to import and export an XCR to the device server

file system. It can also be used to import an XCR from an external source such as your local
hard drive.
FTP—The device server FTP server can export and import XCRs when an FTP get or put

command on the filename matchport_bg_pro.xcr is requested. On export (FTP get of
matchport_bg_pro.xcr), the FTP server obtains the current XCR from Evolution OS and sends
it as a file. On import (FTP put of matchport_bg_pro.xcr), the FTP server processes the file by
sending it directly to the XML engine. In both cases the device server filesystem is not
accessed. The file matchport_bg_pro.xcr is not read from or written to the file system. See
FTP in the MatchPort® b/g Pro Embedded Device Server User Guide.

Best Practices

You can import or export an entire XCR, or just a portion of it, by specifying the group name and/or
group instances. In the examples below, import and export operations are performed from the CLI
on the local filesystem and require a XCR on the local filesystem. The Web Manager provides the
same functionality.
Caution: Using Microsoft Word to edit and save an XCR will change the format of
the file and make it incompatible with Evolution OS. This is true even if
the file is saved as Plain Text (.txt) or an XML Document (.xml). Notepad,
a third party text editor, or a specialized XML editor should be used
instead.

Importing

The following syntax can be used to import configurations from a file:
xcr import <file>
xcr import <file> <groups and/or group:instances>
The first line imports all groups specified in the XML config record named in <file>. Any filename
is valid, and the file name and extension are not important.
Caution: The filename matchport_bg_pro.xsr.xcr is not acceptable, because
performing a FTP get on that name produces the current configuration
and does not perform an FTP from the filesystem. Also, the filename
matchport_bg_pro.xsr.xsr is not acceptable, because performing an
FTP get on that name produces the current status and does not get
anything from the filesystem.
In the second line:
Instance follows group with a colon (see the third example on the next page).

Multiple groups are separated with a comma.

Any white space requires the list of groups to be quoted.

Only the named groups get imported, even if the XCR contains additional XCR groups.

MatchPort® b/g Pro Embedded Device Server Command Reference
4: Configuration Using XML
18
