Lantronix MatchPort b/g Pro Command Reference Manual page 139

reassert
show
show command mode
show history
show line
show statistics
state disable
state enable
stop bits 1
stop bits 2
terminal <line>
terminal network
threshold <bytes>
tunnel <line>
write
xoff char <control>
xon char <control>
link (config-wlan:wlan0) level commands
apply wlan
choice <instance>
clrscrn
default out of range scan interval
exit
out of range scan interval <seconds>
MatchPort® b/g Pro Embedded Device Server Command Reference
Asserts line status with current configured values.
Displays the current status.
Shows the command mode settings for the current line.
Displays the last 20 commands entered during the current
CLI session.
Displays the current configuration.
Shows the line statistics.
Disables the line so data cannot be sent/received.
Enables the line so data can be sent/received.
Uses one stop bit after data on the line.
Uses two stop bits after data on the line.
Enters the configure-terminal level.
<line> = number of the terminal line (serial port) to be con-
figured.
Enters the configure-terminal level for the network.
Sets the threshold in bytes. After this many bytes are re-
ceived, they are
forwarded without delay.
Enters the tunnel level.
<line> = number of the tunnel line (serial port) to be con-
figured.
Stores the current configuration in permanent memory.
Sets the xoff character for use with software flow control
on this line.
The character may be input as text, control, decimal, or
hex.
A control character has the form <control>C.
A decimal value character has the form \99.
A hex value character has the form 0xFF.
Sets the xon character for use with software flow control
on this line.
The character may be input as text, control, decimal, or
hex.
A control character has the form <control>C.
A decimal value character has the form \99.
A hex value character has the form 0xFF.
Try out WLAN settings without saving them to Flash.
If the settings do not work, when you reboot the device,
it will still have the original settings.
Enters the next lower level.
Specify the instance for the next lower level.
Clears the screen.
Restores the default value to the out-of-range scan inter-
val (30 sec).
Exit back to interface configuration level
Sets the value of the out-of-range scan interval.
<seconds> = Interval between scans when the device has
deemed it is
out of range of networks in its configuration.
NOTE: Scans use more power than idling. The longer the
interval the less
power consumption. But also more possible detection
latency when moving
within range of a network.
5: Commands and Levels
139
