Menu
Monitor ID Display
Function and operation ([
Area Marker1: An area marker 1 is displayed on the screen.
Area Marker2: An area marker 2 is displayed on the screen.
Center Marker: The center marker is displayed on the screen.
Aspect Marker-Line: The line of the aspect marker is displayed on the screen.
Aspect Blanking-Half: Aspect Blanking is set to half blanking.
Aspect Blanking-Black: The blanking level of Aspect Blanking is set to 0% black level.
Note
Use the controller with software version 1.6 or higher to assign Center Marker, Aspect
Marker-Line, Aspect Blanking-Half or Aspect Blanking-Black to a function button of the
controller.
Side by Side: The screen is displayed in the side by side display mode.
Wipe: The screen is displayed in the wipe display mode.
Butterfly: The screen is displayed in the butterfly display mode.
Blending: The screen is displayed in the blending display mode.
Error Notify Clear: Clears the notification detected in the gamut error detection. (OSD
Notification)
Note
Wipe, Butterfly, Blending, and Error Notify Clear can be assigned to the controller.
However, the display mode using these functions cannot be supported on BVM-F series
monitors.
Audio Level Meter: The audio level meter is displayed.
ALM Hold Reset: The peak hold of the audio level meter is canceled.
Time Code: The time code is displayed.
Note
Use the controller with software version 1.4 or higher to assign Audio Level Meter, ALM
Hold Reset or Time Code to a function button of the controller.
Difference: The difference between the luminance of the left 3D video signal and that of
the right signal is displayed.
Note
Use the controller with software version 1.6 or higher to assign Difference to a function
button of the controller.
Checkerboard: The left and right 3D video signals are displayed in a checkerboard
pattern.
L/R Switch: The left and right 3D video signals are displayed alternately by switching.
Note
Use the controller with software version 1.5 or higher to assign Checkerboard or L/R
Switch to a function button of the controller.
Horopter Check: The left and right 3D video signals are displayed in the mode selected
in Horopter Check (page 66) in the 3D Setting menu of the Function Setting menu.
Flip H: The 3D video signals are inverted horizontally and displayed.
Note
Use the controller with software version 1.6 or higher to assign Horopter Check or Flip H
to a function button of the controller.
Black Frame Insertion: The signal is displayed in black frame insertion mode (only for
BVM-L and PVM-L series).
Black Detail Mode: The signal is displayed in black detail mode (only for BVM-L and
PVM-L series).
Note
Use the controller with software version 1.3 or higher to assign Black Detail Mode to a
function button of the controller.
Degauss: The CRT is degaussed (only for BVM-A series).
Sets display mode of the display window.
[On]: Always displayed.
Auto: Displayed during operating by the remote connection and disappears
automatically after operation.
Off: Not displayed.
]: factory setting)
85
Controller Menu
