Printer Commands
Text Mode Response
>RESTARTED<
>READY<
>CUTTER ERROR<
>TAKE LABEL<
>LOW STOCK<
>INPUT 1<
>INPUT 2<
>TRAY FULL<
>PRINTER PAUSED<
>TOF ERROR<
>OVER VDD<
>UNDER VDD<
>OVER TEMP<
>DATA ERROR<
>STOCK NOT LOADED<
>BUTTON PRESSED<
>CODE 12<
5.2

Printer Configuration Commands

The following commands are used to set up printer configuration. Most of these commands
are non-volatile and, therefore, do not need to be present unless changes are desired.
Note: When the printer is in the DEFAULT MODE, factory settings control printer operation.
This provides a starting point for re-establishing communication with the printer so that user
settings can be sent to the printer. The statistics label printed when the printer is entered
into the DEFAULT MODE reflects current user settings, not factory default settings.
5.2.1

Baud Rate

This non-volatile command changes the serial port communication speed.
Note: Unless otherwise noted, the factory default baud setting is 115,200. The baud rate
will be temporarily set to 115,200 when the printer is in the Diagnostic Mode if the user
setting is different. The user set baud rate will resume after a "soft reset" (^D32) or cycling
the power to the printer.
5-4
Byte Mode
Response
1A
06
07
16
19
0E
21
09
10
1F
1E
1C
1D
15
22
C0
23
Table 5-1 Enquiry Responses
324M/424M Operator's Manual - 880026-1001
Definition
Printer has been reset
Normal condition
Cutter cannot rotate
Printer is waiting for label to be taken
Media supply is low or out
Input sensor #1 active
Input sensor #2 active
Printed label tray is full
Printer is paused
Top of Form is not sensed properly
VDD voltage is out of operational range
VDD voltage is out of operational range
Print Head is too hot
Communication error
Printer power on without media installed
Print button configured to report
message when pressed
CRC value does not match stored value
Chapter 5
