Bar Codes
8.1.13 MaxiCode, TCI 38
MaxiCode is a fixed-size, 2-D matrix symbology that is capable of encoding the entire ASCII
character set (0 to 255) and up to 93 characters per symbology. Modes 2 through 6 of the
AIM Internal MaxiCode specification are supported. Modes 0 and 1 are obsolete and are
not supported.
MaxiCode may encode non-printable characters, and Modes 2 and 3 require certain control
characters for compatibility with transport industry standards. In order to properly specify a
control character in a MaxiCode data string, use the pound symbol ("#") followed by the two
digits Hexadecimal value of the control code. For example, "#01" specifies "Control-A"
(ASCII SOH) and "#1D" specifies "Control-]" (ASCII GS). Enter "##" in order to include an
actual pound symbol in the data string. Refer to Table 8-2 for the "#" equivalents that may
be used.
The following is the command structure of the ^D71 which is used to load the data for
Maxicode:
^D71<CR>
Mode<CR>
Symbol Number<CR>
Total Number<CR>
Country code<CR>
Service Code<CR>
Zip Code<CR>
Mode – barcode mode (1 through 6).
Symbol Number – Maxicode barcodes can be chained together. This one is the Nth
barcode series.
Total Number – Total number of barcodes in the series.
Country Code – Three digits.
Service Code – Three digits.
Zip Code – 9 digits.
The data string associated with a MaxiCode field shall begin with ":", end with control
character "^\", and be formatted according to the Mode selected (2-6).
Mode 2
Mode 2 may have either of the following formats:
Format 1
[)>#1e01#dYYPPPPPPPPP#1dCCC#1dSSS#1dA..A#1dB..B#1dC..C#1e#04
Where:
#1e is the ASCII RS character
#1d id the ASCII GS character
