Printer Commands
Text Mode Response
>RESTARTED<
>READY<
>CUTTER ERROR<
>TAKE LABEL<
>LOW STOCK<
>INPUT 1<
>INPUT 2<
>TRAY FULL<
>PRINTER PAUSED<
>TOF ERROR<
>OVER VDD<
>UNDER VDD<
>OVER TEMP<
>DATA ERROR<
>STOCK NOT LOADED<
>BUTTON PRESSED<
>CODE 12<
>BROWNOUT RECOVERY<
>FAIL TIMEOUT<
>FAIL SIZE<
5.2

Printer Configuration Commands

The following commands are used to set up printer configuration. Most of these commands
are non-volatile and, therefore, do not need to be resent unless changes are desired.
Note: When the printer is in the DEFAULT MODE, factory settings control printer operation.
This provides a starting point for re-establishing communication with the printer so that user
settings may be sent to the printer. The statistics label printed when the printer entered the
DEFAULT MODE reflects current printer settings and not the factory default settings.
5-12
Byte Mode
Response
1A
06
07
16
19
0E
21
09
10
1F
1E
1C
1D
15
22
C0
FF
Table 5-2 Enquiry Responses
Definition
Printer has been reset
Normal condition
Cutter cannot rotate
Printer is waiting for label to be taken
Media supply is low or out
Input sensor #1 active
Input sensor #2 active
Printed label tray is full
Printer is paused
Top of Form is not sensed properly
VDD voltage is out of operational range
VDD voltage is out of operational range
Print Head is too hot
Communication error
Printer power on without media installed.
Print button configured to report message
when pressed.
CRC value does not match stored value.
Printer entered and recovered from a
brownout power condition
Timeout failure occurred using the D149
Image Print Mode
Incorrect size of the image was received
using the D149 Image Print Mode
428M Operator's Manual - 880028-0112
Chapter 5
