Printer Commands
2 >BUTTON PRESSED< status enable: When enabled, pressing the
button will cause the printer to report the >BUTTON PRESSED< or
0xC0 depending on the printer's ^D21 response mode configuration.
This is typically used on systems that preload a batch of jobs to the
printer but wait on the >BUTTON PRESSED< message before sending
the print command.
3 Type of Top Of Form Sensor: The leading edge of the label stock can
be sensed using either a reflective sensor or a transmissive sensor.
The correct type of sensor is determined by the printer hardware
configuration being used.
4 Enable Power ON TOF: This bit controls whether or not the printer will
do an automatic Top Of Form (TOF) when it is turned ON.
5 Enable Button TOF: This bit determines whether the GREEN button
functions as a Top Of Form or as defined by SW#2, bit 4. The button is
always configured to clear error conditions.
6 Enable AutoLoad: This bit determines whether the AutoLoad function
is ON or OFF. When Autoload is enabled and a no media to media
transition is detected by the printer's internal transmissive sensor, the
printer will step the pulled media into the printer and perform either a
TOF or a Form Feed depending on SW#5, bit 7 configuration.
7 Type of AutoLoad: This bit determines whether the AutoLoad function
uses the Top Of Form sensor (TOF), or if it uses the Form Feed
technique.
8 General Purpose Mode: If enabled, the printer will enter a special
mode of communications using the Ethernet port.
5-10
1 = Enable >BUTTON PRESSED<
0 = Disabled
1 = TOF is TRANSMISSIVE
0 = TOF is REFLECTIVE
1 = Enable Power-ON TOF
0 = Disable
1 = Button is TOF
0 = Button is PRINT
1 = AutoLoad is ON
0 = AutoLoad is OFF
1 = AutoLoad + TOF
0 = AutoLoad + FF
1 = Enable General Purpose Mode
0 = Disable General Purpose Mode
