Designing Labels Using LDS
4.6.6 CGN (Character Generator Number)
The CGN parameter is a numeric entry that determines the representation and size of
embedded font and bar codes as well as the memory location of graphic images that have
been selected by the TCI parameter.
4.6.6.1 Embedded Fonts
The Model 324M and 424M printers provide seven resident Helvetica style 203 dpi
embedded fonts that can be selected using the CGN when text is selected by the
appropriate TCI value.
CGN POINT
VALUE SIZE
1 6
2 8
3 10
4 12
5 14
7 12
8 12
4.6.6.2 Downloadable Fonts and Graphics
When selecting downloadable fonts and graphics using TCI value of "7" or "8", the CGN
denotes the memory slot (1-255) where the font or graphic has been stored. See Chapters
6 and 7 for additional information regarding downloadable fonts and graphics.
For example: If a graphic had been stored into RAM (volatile) memory slot 1 (see Chapter 5
for additional information), the proper TCI would be "8" and the CGN value would be "1".
CGN POINT
VALUE SIZE
10 6
11 6
12 8
13 8
14 10
15 10
16 12
4-14
Embedded Bitmapped Fonts
FONT TYPE
Swiss™721 Bold
Swiss™721 Normal
Swiss™721 Normal
Swiss™721 Normal
Swiss™721 Normal
OCR-A
OCR-B
Table 4-5 CGN—Embedded Fonts
Standard Downloadable Font Set
Swiss™721 Normal 0 degree
Swiss™721 Normal 90 degree
Swiss™721 Normal 0 degree
Swiss™721 Normal 90 degree
Swiss™721 Normal 0 degree
Swiss™721 Normal 90 degree
Swiss™721 Normal 0 degree
FONT SAMPLE
6pt ABCDEFGHIJKLMNOPQRSTUVWXYZ1234567890
8pt ABCDEFGHIJKLMNOPQRSTUVWXYZ1234567890
10pt ABCDEFGHIJKLMNOPQRSTUVWXYZ
12pt ABCDEFGHIJKLMNOPQRSTU
14pt ABCDEFGHIJKLMNOPQR
ABCDEFGHIJKLMNOPQRSTUVWXYZ
ABCDEFGHIJKLMNOPQRSTUVWXYZ
FONT TYPE
