Printer Commands
Text Mode Response Byte Mode Response
>RESTARTED<
>READY<
>CUTTER ERROR<
>TAKE LABEL<
>LOW STOCK<
>INPUT 1<
>INPUT 2<
>TRAY FULL<
>PRINTER PAUSED<
>TOF ERROR<
>OVER TEMP<
>DATA ERROR<

5.2 Basic Printer Configuration Commands

The following commands are used to set up basic printer configuration. Most of these
commands are non-volatile, and therefore do not need to be present unless changes are
desired. Changes made with these commands will not take effect until the printer's power is
cycled "OFF" and "ON," or a "soft reset " command (^D32 command) is sent to the printer.
Note: When the printer is in the DEFAULT MODE, factory settings control printer operation.
This provides a starting point for re-establishing communication (factory default baud rate is
115,200) with the printer so that user settings can be reset should settings become
scrambled.
The statistics label printed when the printer is entered into the DEFAULT MODE reflects
current user settings, not factory default settings.
5.2.1

Baud Rate

This non-volatile command changes the serial port communication speed.
Note: Unless otherwise noted, the factory default baud setting is 115,200. The baud
rate will be temporarily set to 115,200 when the printer is in the Diagnostic Mode if
the user setting is different. The user set baud rate will resume after a "soft reset"
(^D32) or cycling the power to the printer.
5-4
1A
06
07
16
19
0E
21
09
10
1F
1D
15
Table 5-1 Enquiry Responses
224/424 Operator's Manual - 880027-1000
Definition
Printer has been reset
Normal condition
Cutter cannot rotate
Printer is waiting for label to be taken
Media supply is low or out
Input sensor #1 active
Input sensor #2 active
Printed label tray is full
Printer is paused
Top of Form is not sensed properly
Print Head is too hot
Communication error
Chapter 5
