Microcom 324M Operator's Manual page 63

Chapter 5
The 48-466 emulation supports unique 48-466 command operations
and will process the data in the same way when technically possible.
These unique operations are briefly discussed below. Please consult
the Model 48-466 Operators Manual for additional information regarding
the command operation.
a) The printer supports the CGN lookup as defined above and in the
b) The 48-466 graphic structure is used when the emulation command
c) The ^D59 command allows format slots 121 to 128 to be overwritten
d) The ^Ax^D125 command controls the location of the euro character
The 48-466 and X24 code bases are not fully compatible, so the
emulation does have some limitations. The known limitations are briefly
mentioned below:
a) The 48-466 data stream should not use an Attribute Number of 2
b) The CS value used in conjunction with the AN set to a 2 to produce
c) Fields that were using an AN of 2 and CS for negative kerning may
Once these changes are made, the resulting data may be sent to a 48-
466 and 424M printer to produce the same printed image in most
cases.
324M/424M Operator's Manual - 880026-1001
48-466 Operators manual when the emulation command is enabled.
is enabled and discussed in greater detail the 48-466 Operators
manual.
to when the emulation command is enabled.
as provided in the model 48-466 printers. The euro character which
by default is mapped to location 0xE3 (227 decimal) can be moved
to another location specified by the x if x>0. If x=0 no remapping will
take place and the euro will stay at location 0xE3. Also if the printer
must be configured to use a code page other than the default (0000)
code page.
(fixed/non-proportional) which is the seventeenth parameter. It is
not technically possible to emulate this model 48-466 feature.
a negative kerning effect should be removed and the field defaulted.
th
This is the 11 field defined in the format lines.
require that their placement coordinates are adjusted to produce the
same outputs.
1 = Enable 48-466 Emulation Mode
0 = Disable 48-466 Emulation Mode
Printer Commands
5-13
