Chapter 5
^A ^D COMMAND
20
0 110 bps
1 150 bps
2 300 bps
3 600 bps
4 1,200 bps
5 2,400 bps
6 4,800 bps
7 9,600 bps
8 19,200 bps
9 38,400 bps
10 57,600 bps
11 115,200 bps
5.2.2

Software Switches

The Software Switch settings are non-volatile. The DIP Switch commands may use either
^A (decimal) or ^AB (binary) values. Since each bit represents a setting for the printer, the
soft switches are always reported as binary.
Example: ^AB10100001^D21<CR> configures serial port #1 for text equivalent enquiry
responses, accept control codes, disables echo, and enables XON/XOFF flow control.
^AB12345678 (each bit is represented by a numeric position number)
5.2.2.1

Software Switch #1

^AB ^D COMMAND
XX 21 Change SW1: Software Switch #1.
^AB12345678 (each bit is represented by a numeric position number)
Position:
1,2 Enquiry Response: This determines what the printer will send back in
response to an enquiry command.
3 Control Codes: This position sets how the printer handles incoming
control codes.
4 Port #1 Parity Selection: Sets the printer port #1 parity for serial
communication.
324M/424M Operator's Manual - 880026-1001
00 = Control Codes
10 = Text Equivalent
1 = Ignore Incoming Control Codes
0 = Accept Incoming Control Codes
1 = Odd Parity
0 = Even Parity
Printer Commands
5-5
