Getting Started

3.2 Connecting the Printer

The printer's may be interfaced to PC's, mini-computers, main frames, and special purpose
machines using the available communications ports described in the following sections.
3.2.1

Printer Power

Microcom Corporation offers three (3) different "Desktop" universal power supplies as
options. Any power supply that conforms to the standard supply specifications listed in
Table 3-1 below may be used. The printer requires a universal +24VDC power supply that
operates in the 100-240 VAC; 50-60 Hertz range; 4 Amps. The power supply should
operate in an "output foldback mode" during an overload situation rather than a shutdown
and restart attempt; sometimes referred to as a "Hiccup" mode. Contact your Microcom
Corporation representative for any questions regarding power adapter requirements and/or
specifications.
AC Input:
DC Output:
Power Rating:
Overload Protection:
Maximum Transient Load:
Printer Power Connector:
Table 3-1
AC Input:
DC Output:
Power Rating:
Overload Protection:
Maximum Transient Load:
Printer Power Connector:
Table 3-2
AC Input:
DC Output:
Power Rating:
Overload Protection:
Maximum Transient Load:
Printer Power Connector:
Table 3-3
3-2
100-240 VAC, 50/60 HZ, 4A
+24V @ 0.2 ~4.16A +/- 5%
100 Watts, no cooling, 40
Output Voltage Foldback Mode
12 cycles @ 2.1ms rep. rate;
35A, 650µs pulse
Standard 4-pin power mini-DIN
100 Watt Power Supply, w/o Fan 40
100-240 VAC, 50/60 HZ, 4A
+24V @ 0.2 ~6.25A +/- 5%
150 Watts, internal fan cooling, 60
Output Voltage Foldback Mode
12 cycles @ 2.1 ms rep. rate;
35A, 650 µs pulse
Standard 4-pin power mini-DIN
150 Watt Power Supply, with Fan 60
100-240 VAC, 50/60HZ, 4A
+24V @ 0.2 ~4.16A +/- 5%
85 Watts, no cooling, 40
Output Voltage Foldback Mode
12 cycles @ 2.1ms rep. rate;
35A, 650µs pulse
Standard 4-pin power mini-DIN
85 Watt Power Supply, w/o Fan 70
324M/424M Operator's Manual - 880026-1001
Chapter 3
°
