Printer Commands
5.8

Label Header Parameter Override Commands

It is possible to override label header parameters by adding one or more of the following
commands after the label format.
^A ^D COMMAND
40 Clears Commands 41 through 51.
XX 41 Load Number of Fields in Layout (HFM): The ^Axx specifies the value.
XX 42 Load Label Width in dots (LXS): The ^Axx specifies the value.
XX 43 Load Label Height in dots (LSY): The ^Axx specifies the value.
XX 44 Load the Web Size in dots (WEB): The ^Axx specifies the value.
XX 45 Load the Gap Size in dots (GAP): The ^Axx specifies the value.
XX 46 Load Print Speed: The ^Axx specifies the value.
XX 47 Load the Label Control Byte (LCB): The ^Axx specifies the value.
XX 48 Load the Number of Steps to Activate Gap Detector (AGD): The ^Axx
specifies the value in Dot Rows.
XX 49 Load the Number of Steps Past Gap (SPG): The ^Axx specifies the value
in Dot Rows.
XX 50 Load X Direction Offset (OFX): The ^Axx specifies the value.
XX 51 Load Y Direction Offset (OFY): The ^Axx specifies the value.
5.8.1

Serial Number Commands

The following commands, ^D80 through ^D89, are used for the serial number function
commands of the printer. The printer can increment or decrement any single serial number
on the label by any amount. If the format contains more than one serial number, then all
serial number fields can only increment or decrement by a value of one. Single and Multiple
serial number commands cannot be used on the same format. Please note that the ^D57
command clears most of the serial number commands. Therefore, all serial number
commands should be placed after the ^D56 command or just prior to the ^D3 command.
The following two commands are valid for both single and multiple serial number functions:
^A ^D COMMAND
80 Clears Commands 86, 88, 89.
81 Disable Serial Number Function: This command disables both single and
multiple serial number functions.
5-30 324M/424M Operator's Manual - 880026-1001
Chapter 5
