5.6.6 CGN (Character Generator Number)
The CGN parameter is a numeric entry that determines the representation and size of
embedded font and bar codes as well as the memory location of graphic images that have
been selected by the TCI parameter.
5.6.6.1 Embedded Fonts
The Model 322M has seven resident Helvetica style embedded fonts that can be selected
using the CGN when text is selected by the appropriate TCI value.
CGN POINT
VALUE SIZE
1 6
2 8
3 10
4 12
5 14
7 12
8 12
5.6.6.2

Downloadable Fonts and Graphics

When selecting downloadable fonts and graphics using TCI value of "8", the CGN denotes
the memory slot (1-255) where the font or graphic has been stored. See Chapters 7 and 8
for additional information regarding downloadable fonts and graphics.
For example: If you had stored a graphic into memory slot 1 (see Chapter 7 for additional
information), the proper TCI would be "8" and the CGN value would be "1".
5.6.6.3

Embedded Bar Codes

Certain bar codes can be printed using various ratios and character spacing options. The
following table (Table 11) illustrates these options. See Chapter 9 for more detailed
information on designing label formats using bar code symbologies. Some bar codes do not
require a CGN value and should be omitted by entering the comma delimiter.
For Example: If a TCI of 40 is selected the CGN will be omitted by entering nothing for the
CGN and surrounding the parameter with the comma delimiter.
1,200,200,10,40,,0,0,100,1
34
Embedded Bitmapped Fonts
FONT TYPE
Swiss™721 Bold
Swiss™721 Normal
Swiss™721 Normal
Swiss™721 Normal
Swiss™721 Normal
OCR-A
OCR-B
CGN – Embedded Fonts
Table 10
FONT SAMPLE
6pt ABCDEFGHIJKLMNOPQRSTUVWXYZ1234567890
8pt ABCDEFGHIJKLMNOPQRSTUVWXYZ1234567890
10pt ABCDEFGHIJKLMNOPQRSTUVWXYZ
12pt ABCDEFGHIJKLMNOPQRSTU
14pt ABCDEFGHIJKLMNOPQR
ABCDEFGHIJKLMNOPQRSTUVWXYZ
ABCDEFGHIJKLMNOPQRSTUVW
XYZ
