4.6.6.2 Downloadable Fonts and Graphics
When selecting downloadable fonts and graphics using TCI value of "7" or "8", the CGN
denotes the memory slot (1-255) where the font or graphic has been stored. Graphics must
point to a "." period character in the field. See Chapters 6 and 7 for additional information
regarding downloadable fonts and graphics.
For example: If a graphic had been stored into RAM (volatile) memory slot 1 (see Chapter 5
for additional information), the proper TCI would be "8" and the CGN value would be "1".
4.6.6.3 Embedded Bar Codes
Certain bar codes can be printed using various ratios and character spacing options. The
following table illustrates these options. See Chapter 8 for more detailed information on
designing label formats using bar code symbols. Some bar codes do not require a CGN
value and should be omitted by entering the comma delimiter.
For Example: If a TCI of 40 is selected the CGN will be omitted by entering nothing for the
CGN and surrounding the parameter with the comma delimiter.
1,200,200,10,40,,0,0,100,1
SYMBOL
Code 39
I 2 of 5
UPC / EAN *
UPC Readable *
Code 128 & UCC / EAN 128 *
Codabar
4-14
POINT
SIZE
24 Swiss™721 Bold 0 degree
24 Swiss™721 Bold 90 degree
12
12 OCR-A Normal 90 degree
12
12 OCR-B Normal 90 degree
8
8 OCR-B Normal 90 degree
Table 4-5 CGN—Embedded Fonts
Bar Code Symbologies
CGN
VALUE
2
3
5
8
2
3
5
-
-
-
2
3
FONT TYPE
OCR-A Normal 0 degree
OCR-B Normal 0 degree
OCR-B Normal 0 degree
RATIO HEIGHT
2:1 1
3:1 1
5:2 1
8:3 1
2:1 1
3:1 1
5:2 1
40 % 1
40 % 1
40 % 1
2:1 1
3:1 1
238B Operator's Manual - 880053-0101
Chapter 4
SPACING FO **
2 0123
2 0123
2 0123
3 0123
- 0123
- 0123
- 0123
- 0123
- 0123
- 0123
- 0123
- 0123
