System Board - Intergraph Zx10 5U System Manual

82
Feature
Expansion Slots
Peripheral Device
Bay
Disk Drive Cage
I/O Ports
Power Supply

System Board

See the System Board Manual for more detailed information about the system board and its
components.
Component
System BIOS
Processors
System Chipset
Combo Controller
SCSI Controller
Audio Controller
Network Controller
Description
One full-length AGP Pro, six full-length PCI, one full-length ISA (shared
with a PCI slot); PCI slots Revision 2.2, two fast-and wide
(66 MHz, 64 bits. 3.3 V/Universal) and four wide (33 MHz, 64 bits,
5 V/Universal)
One 3.5-inch x 1.6-inch internal bay for system disk drive
One 5.25-inch x 1.6-inch internal/external bay for peripheral device
One 5.25-inch x 1.6-inch external bay for CD-ROM drive
One 3.5-inch x 1.0-inch external bay for floppy disk drive
Up to four LVD Ultra3 (LSI 53C1010) or Wide Ultra 2 (LSI 53C896) disk
drives
One PS/2 mouse and one PS/2 keyboard – 6-pin mini-DIN
One parallel (LPT), EPP/ECP – 25-pin DB25
Two serial (COM) – 9-pin DB9
Two Universal Serial Bus (USB) – 12 MB/sec
One SCSI – Ultra3
Video – SVGA; others vary by controller
Audio – Microphone, line in, line out, MIDI/game
Network – Ethernet
400 Watts, manual-ranging
Description
Phoenix
Intel SC242 processor modules
ServerWorks ServerSet III WS
SMC FDC37B787
LSI 53C1010
Creative ES1373 AudioPCI
Intel 82559
