System Specifications - Intergraph Zx10 5U System Manual

System Specifications

Item
Dimensions
Weight
Equipment rack space requred
Maintenance clearance
AC line voltage (US)
AC line voltage (International)
Power consumption
Recommended room temperature
Recommended room humidity
Heat dissipation
Specifications
8.7 in high x 16.7 in wide x 25.1 in deep
(22.1 cm high x 42.4 cm wide x 63.8 cm deep)
55 LB. (25 kg) fully configured
5U, or 8.75 in (22.2 cm)
36 inches (91.4 cm) front and back
90 – 132 VAC, 47 – 63 Hz, 1 phase, 15A/125 V receptacle
180 – 264 VAC, 47 – 63 Hz, 1 phase, 15A/250 V receptacle
285 W; 3.4 A at 120 VAC maximum configuration
50 to 90 F (10 to 32 C); optimum 70 F (21 C)
20% to 80% (non-condensing); optimum 50%
1,265 BTU/hr
83
