78
Floppy Disk Drive Cable
Connector
1
1
2
EIDE Device Cables
1
Connector
1
2
3
SCSI Disk Drive Cage Cable
1
Connector
1
2
3
4
5
6
Connects To
2
Floppy disk drive controller on system board
Floppy disk drive
3
2
Connects To
EIDE connector on system board
EIDE CD-ROM drive
EIDE device (optional)
3
4
2
5
Connects To
SCSI Channel B connector on system board
SCSI disk drive in disk drive cage
SCSI disk drive in disk drive cage
SCSI disk drive in disk drive cage
SCSI disk drive in disk drive cage
SCSI terminator module
6
