64
To avoid damaging an expansion card and voiding its warranty, take the following precautions:
Handle the expansion card only by the edges. Do not touch the metallic finger contacts.
Do not bend, twist, drop, or otherwise handle the expansion card carelessly.
Do not expose the expansion card to moisture or extreme temperatures.
Do not remove the expansion card from its antistatic package until you are ready to install it.
To replace an expansion card:
WARNING
The system is always on when connected to AC power. Before performing this
task, disconnect the system's power cord from its AC power outlet.
1.
Remove the top cover. See Chapter 7, "Gaining Access to System Components."
2.
Disconnect any external and internal cables from the expansion card.
3.
Remove and retain the retaining screw that secures the card to the card guide.
4.
Pull the card straight out of its socket, and place the card on an antistatic surface.
Slot Connector
(Typical)
Retaining Screw
Expansion Card
(Typical)
(Typical)
