QUICK REFERENCE GUIDE

I Installation

D Installation methods
• Single body installation
• The supplied MB-85
the controller to the main unit. (Use the supplied 20 cm sep-
aration cable.)
• The supplied mounting bracket (or optional MB-17A) can be
used for the main unit installation.
I
Transceiver
is used to mount
COMBINATION BRACKET
• Remote installation
Main body
• Optional MB-84
REMOTE CONTROLLER BRACKET
1155 can be used for installation.
SEPARATION CABLE
• Optional OPC-1156
SEPARATION CABLE
for extend the separation cable.
• Optional MB-65
MOUNTING BASE
front panel mounting possibilities.
• Optional OPC-440
MICROPHONE CABLE
(2.5 m) are available to extend the microphone cable.
• Optional OPC-441
SPEAKER CABLE
tend the speaker cable.
Front panel
and OPC-
(3.5 m) is available
is available for increasing
(5.0 m) and OPC-647
(5.0 m) is available to ex-
