I Options - Icom IC-2725E Instruction Manual

I Options

HM-133 -
REMOTE CONTROL MICROPHONE
Wired remote control microphone with key backlight. Same as that
supplied with the transceiver.
HM-118TN
DTMF MICROPHONE
HM-118N
HAND MICROPHONE
HS-62
FLEXIBLE MOBILE MICROPHONE
+ OPC-589
ADAPTER CABLE
For all-round mobile operation.
OPC-1155
SEPARATION CABLE
Remotely install the transceiver. Cable length: 3.5 m
OPC-1156
CONTROLLER EXTENSION CABLE
Extends the OPC-1155 separation cable.
MB-84
REMOTE CONTROLLER BRACKET
Used for remote installation. OPC-1155
for installation.
MB-85
COMBINATION BRACKET
Same as that supplied with the transceiver.
MB-65
MOUNTING BASE
Mounts the remote controller on to variety of place in vehicle. MB-84
is required for mounting.
MB-17A
MOBILE MOUNTING BRACKET
One-touch bracket. Transceiver main unit easily attached or re-
moved.
OPC-440/OPC-647
MIC EXTENSION CABLES
OPC-440: 5.0 m; OPC-647: 2.5 m
+ HS-15SB
SWITCH BOX
is required
SEPARATION CABLE
SPECIFICATIONS AND OPTIONS
OPC-441
SPEAKER EXTENSION CABLE
Cable length: 5.0 m
SP-7/SP-10
EXTERNAL SPEAKERS
SP-7: For base station use. Cable length: 1.0 m
SP-10: For all-round mobile operation. Cable length: 1.5 m
OPC-347/1132
DC POWER CABLES
OPC-347: 7.0 m
OPC-1132: 3.0 m Same as that supplied with the transceiver.
CS-2720
CLONING SOFTWARE
Provides quick and easy programming items, such as memory chan-
nels, set mode contents for local repeater frequencies, via PC's USB
terminal. RS-232C type cloning cable, OPC-478, also available.
OPC-474
CLONING CABLE
Used for data cloning between transceivers.
13
+ OPC-478U
CLONING CABLE
