SPECIFICATIONS AND OPTIONS

I Specifications
D D GENERAL
• Frequency coverage
Europe
Italy
• Type of emission
• Number of memory channels : 212 (incl. 10 scan edges and 2 calls)
• Frequency resolution
• Operating temperature range : –10°C to +60°C
• Frequency stability
• Power supply requirement
• Current drain
(at 13.8 V DC: approx.)
Transmit
Receive
(simultaneous receive)
• Antenna connector
• Dimensions
(proj. not included)
Main Unit
Remote controller
• Weight
(approx.)
Main unit
Remote controller
73
:
144–146 MHz, 430–440 MHz
144–146 MHz, 430–434 MHz,
435–438 MHz
: FM, AM
(Receive only)
: 5, 10, 12.5, 15, 20, 25, 30, 50 kHz
: ±10 ppm
(–10°C to +60°C)
: 13.8 V DC ±15%
:
at 50 W 12 A
standby 1.2 A
max. audio 1.8 A
(50 Ω)
: SO-239
:
× 40(H) × 187(D) mm
140(W)
140(W) × 50(H) × 24.5(D) mm
:
1.25 kg
(incl. separation cable)
150 g
D D TRANSMITTER
• Modulation system : Variable reactance frequency mod-
• Output power : VHF
• Max. frequency deviation : ±5.0 kHz
• Spurious emissions : Less than –60 dB
• Microphone connector : 8-pin modular
D D RECEIVER
• Receive system : Double-conversion superheterodyne
• Intermediate frequencies :
Left band
Right band
• Sensitivity
(FM: at 12 dB SINAD/AM: at 10 dB S/N)
144 MHz band
430 MHz band
• Squelch sensitivity : Less than 0.13 µV
(threshold)
• Selectivity (typical) :
Wide
Narrow
• Spurious and image rejection : More than 60 dB
• AF output power : More than 2.4 W
(at 13.8 V DC)
: 3-conductor 3.5 (d) mm/8 Ω
• Ext. speaker connectors
All stated specifications are subject to change without notice or obligation.
ulation
50/15/5 W
(approx.)
UHF 35/15/5 W
(approx.)
(wide)
±2.5 kHz
(narrow: Left band only)
(600 Ω)
1st: 38.85 MHz, 2nd: 450 kHz
1st: 46.05 MHz, 2nd: 455 kHz
:
Less than 0.18 µV/0.45 µV typ.
Less than 0.18 µV/—
More than 12 kHz/6 dB
Less than 30 kHz/60 dB
More than 6 kHz/6 dB
Less than 20 kHz/60 dB
at 10% distortion with
an 8 Ω load
