Mainboard Overview - Bottom (Connectors)
1
2
8
11
9
10
3
4
5
6
7
Mainboard Overview - Bottom (Connectors) 1 - 11
Introduction
Figure 10
Mainboard Bottom
Connectors
1. Battery Connector
2. DC-In Jack
3. DVI Port
4. USB 2.0 Ports
5. RJ-45 LAN Jack
6. HDMI-Out Port
7. VGA Fan 1
8. VGA Fan 2
9. ODD Connector
10. HDD Connectors
11. CPU Fan Connector
