Mainboard Overview - Bottom (Connectors)
10
4
3
2
1
9
8
5
6
7
Mainboard Overview - Bottom (Connectors) 1 - 11
Introduction
Figure 10
Mainboard Bottom
Connectors
1. Battery Connector
2. HDD Connectors
3. Thermal Sensor
Connector
4. CPU Fan Connector
5. VGA Fan
6. ODD Connector
7. Multi-in-1 Card
Reader
8. RJ-45 LAN Jack
9. DVI Port
10. DC-In Jack
