Introduction
External Locator - Left Side & Rear View
Figure 4
Left Side View
1. RJ-11 Modem
Jack
2. USB 2.0 Port
3. Mini-IEEE 1394
Port
4. 7-in-1 Card
Reader
5. Optical Device
Drive Bay (for
DVD Device)
6. Cable (CATV)
*
Antenna Jack
*Enabled with Optional TV
Tuner Only
Figure 5
Rear View
1. Vent/Fan Intake/
Outlet
2. Security Lock Slot
(W860CU Only)
3. HDMI-Out Port
4. DC-In Jack
5. 2 * USB Ports
6. RJ-45 LAN Jack
7. Rear Cover
(W870CU Only)
1 - 6 External Locator - Left Side & Rear View
W860CU
4
3
2
1
W870CU
4
3
2
1
6
W860CU
2
1
3
W870CU
3
1
4 5
7
5
5
6
1
5
4
5
1
