Introduction
External Locator - Left Side & Rear View
Figure 1
Left Side View
1. RJ-11 Modem
Jack
2. Cable (CATV)
*
Antenna Jack
3. 7-in-1 Card
Reader
4. Mini-IEEE 1394
Port
5. USB 2.0 Port
6. Optical Device
Drive Bay (for
DVD Device)
*Enabled with Optional TV
Tuner Only
Figure 2
Rear View
1. Vent/Fan Intake/
Outlet
2. HDMI-Out Port
3. DC-In Jack
4. 2 * USB Ports
5. Rear Cover
1 - 6 External Locator - Left Side & Rear View
W860CU
3 4 5
1 2
W860CU
1
2
6
1
3 4
5
