Removing the Modem

1. Turn off the computer, remove the battery
2. The modem will be visible at point
3. Remove screws - from the modem module.
2 3
4. Lift the modem up off the socket
5. Lift the modem up and off the computer.
6
a.
1
b.
2
3
(page 2 - 5), and remove the hard disk bay cover
on the mainboard.
1
and separate the modem from the connector
4
d.
c.
5
4
(page 2 - 6).
.
5
6
Removing the Modem 2 - 13
Disassembly
Figure 9
Modem Removal
a. Remove the cover and
locate the modem.
b. Remove the screws.
c. Lift the modem up off the
socket and disconnect
the connector.
d. Lift the modem out.
6. Modem
• 2 Screw
