Stereo Controls

There are two additional controls used for stereo channels (see Multi Format Masters
on page 126).
Page keys display
second page and Signal
Processing In/Out page
• Balance: Rotate the Bal knob left to hear more of the left channel; rotate right
to hear more of their right channel. Rotate left or right until the display reads
100L or 100R to hear only the left or right channel.
Left-to-mono: Press the upper key next to the Bal knob to send the left channel
equally to both the left and right sides of the stereo channel.
HiZ
48V
HPF
Gain
Trim
Bal
LTM
RTM
Dly
Inp
Figure 8-9 Stereo Controls
103
Channels and Strips
Dly
Mtr
Ins
Swap
EQ
Filt
Aphs
Dyn
Bphs
Fad
