CAUTION
If you are using cables not supplied by Intergraph, you must use shielded cables to prevent
excessive electromagnetic interference (EMI). Intergraph cables are designed to reduce the
amount of EMI produced by the system.
NOTE
All cable ports on the base unit and on other Intergraph equipment are keyed or molded to
ensure proper cable attachment. If a cable is not attaching easily, ensure that you are
aligning the cable connector correctly with the port.
NOTE
When connecting the multimedia keyboard to the base unit, the cable labeled Mic connects to
the Microphone jack, and the cable labeled Audio connects to the Line Out jack.
NOTE
The ports on the back on the base unit are labeled using PC 97 compliant icons.
Game/MIDI
COM1
Microphone
Line In
Line Out
COM2
Video Out
Mouse
Keyboard
10/100Base-T Ethernet
VGA In
VGA Out
Parallel
