Intergraph TD-x10 Setup Manual page 17

Game/MIDI
Microphone
Line In
Line Out
10/100Base-T
Ethernet
Keyboard
Mouse
COM1
COM2
Parallel
VGA Out
3. For a desktop system, set the AC voltage switch to the proper line voltage for your
location. If you do not know the proper line voltage for your location, contact your local
power utility.
For a deskside system, the proper line voltage is detected and set automatically by the
power supply.
WARNING Ensure the power switch on the front of the base unit is disengaged (in the out
position). If the power switch is engaged, power will be applied to the system when the
base unit power cord is plugged into the AC outlet, possibly causing equipment
damage.
4. Connect the power cords for the monitor and base unit to an uninterruptible power supply
(UPS) or to a grounded three-prong AC wall outlet. Then connect the power cords to the
base unit and to the monitor.
5. Connect the monitor as described in "Connecting the Monitor" later in this chapter.
6. If setting up a system with an internal RAID disk array, install the RAID disk drives as
described in "Installing a RAID Disk Drive" later in this chapter.
SCSI
Video Out
VGA In
5
