36
Master Disk, Slave Disk
The Master Disk and Slave Disk icons represent parameters for Integrated Device Electronic
(IDE) drives. If installing IDE hard drives, use the Detect Master and Detect Slave utilities to
automatically detect and configure the drives. Refer to "Utility Menu" for more information.
To change the IDE drive parameters:
1. Select Master Disk or Slave Disk.
2. Select USER from the list of drive types.
3. Select each of the following parameters and enter the appropriate values. For more
information, refer to the documentation included with the device.
CYL
HD
WP
LZ
SEC
4. When complete, press

Advanced Setup

The Advanced icon in the AMIBIOS Main Menu allows you to change details of the system's
operation. Each parameter included in the Advanced Setup menu is described below.
System Boot Up Sequence
This parameter specifies the device sequence for system boot up. The default is C:, A:, which
means the system attempts to boot from drive C first. If unsuccessful, it attempts to boot from
drive A. By default, C: is the system hard disk drive and A: is the floppy disk drive. Change
this parameter to A:, C: to boot the system from a diskette in the floppy disk drive. Refer also
to Operating System Boot Device parameter in "Chipset Setup."
Above 1 MB Memory Test
When enabled, this parameter invokes the Power On Self Test (POST) memory routines on
the RAM above 1 MB. If disabled, the BIOS will check only the first 1 MB of RAM.
Memory Test Tick Sound
This parameter enables or disables the ticking sound during the memory test.
Cylinders
Heads
Write Precompensation
Landing Zone
Sectors
or click the close box at the upper left corner of the window.
ESC
