Intergraph TD-x10 Setup Manual page 22

10
To start the system:
1. Turn on power to the base unit and to the monitor. The following events occur:
The power on LED lights.
The CD-ROM drive LED blinks.
The BIOS boot screen displays the American Megatrends logo.
A boot screen or Setup screen displays.
2. On a system running Windows NT Workstation, select Windows NT Workstation at the
boot screen. The operating system starts and displays a logon dialog.
If you are starting the system for the first time, the system boots to a Setup screen. Refer to
Chapter 2, "Setting Up the Software," to set up the operating system software.
To log on to Windows NT Workstation:
1. If the logon dialog does not display, press
2. Type a username and password into the appropriate boxes.
3. If appropriate, type a domain name.
4. Select OK or press
To logoff, restart, or shut down the operating system:
1. Select Shut Down from the Start menu.
2. Perform one of the following steps, as appropriate:
- To log off from the operating system, select the logoff option, and then select OK.
- To restart the system, select the restart option, and then select OK.
- To shut down the system, select the shutdown option, and then select OK.
After shutting down the operating system, press the power switches on the base unit and the
monitor to turn off power to the system.
For more information on starting and stopping the operating system, refer to the operating
system documentation and Help.
CTRL
.
ENTER
+ + to display it.
ALT DELETE
