Example - GE MultiLink ML1200 Instruction Manual

ACCESS USING RADIUS
7.2.2

Example

Example 7-1: Setting port control parameters
802.1X Authenticator Configuration
==================================
Status: Disabled
RADIUS Authentication Server
==================================
IP Address:
UDP Port:
Shared Secret:
ML1200#
auth
ML1200(auth)##
setport port=2 status=enable control=forceauth initialize=assert
Successfully set port control parameter(s)
ML1200(auth)##
auth disable
802.1X Authenticator is disabled.
ML1200(auth)##
authserver ip=3.204.240.1 secret=secret
Successfully set RADIUS Authentication Server parameter(s)
ML1200(auth)##
auth enable
802.1X Authenticator is enabled.
ML1200(auth)##
show auth ports
Port Status Control
======================================================
1 Enabled Auto
2 Enabled ForcedAuth
3 Enabled Auto
4 Enabled Auto
5 Enabled Auto
6 Enabled Auto
-- Port not available
ML1200(auth)##
show auth config
802.1X Authenticator Configuration
==================================
Status: Enabled
RADIUS Authentication Server
==================================
IP Address:
UDP Port:
Shared Secret:
(continued on following page)
7–6
Example 7-1 demonstrates how to secure the network using port access. Ensure there is
no 802.1x or RADIUS server defined. Only one RADIUS server can be defined for the entire
network.
0.0.0.0
1812
Initialize Current State
Deasserted Authorized
Asserted Unauthorized
Deasserted Authorized
Deasserted Unauthorized
Deasserted Unauthorized
Deasserted Unauthorized
3.204.240.1
1812
secret
CHAPTER 7: ACCESS USING RADIUS
The RADIUS server is on port 2. This port is
authenticated manually. If the RADIUS server is
several hops away, it may be necessary to
authenticate the interconnection ports. Make sure
the
setport port=2 status=enable
control=forceauth initialize=assert
is executed before the
The
necessary. However, it is shown for
completeness in case a RADIUS
server was defined with a previously
set authentication scheme.
MULTILINK ML1200 MANAGED FIELD SWITCH – INSTRUCTION MANUAL
command
command.
auth enable
command is not
auth disable
The RADIUS server is
connected on port #2
