GE MultiLink ML1200 Instruction Manual page 177

CHAPTER 10: VLAN
Converting Port VLAN to Tag VLAN (continued)
VLAN ID: 1
Name : Default VLAN
Status : Active
-----------------------------------------------
PORT | MODE
-----------------------------------------------
1 | UNTAGGED |
2 | UNTAGGED |
3 | UNTAGGED |
4 | UNTAGGED |
5 | UNTAGGED |
6 | UNTAGGED |
7 | UNTAGGED |
vlan type=tag
ML1200#
ML1200(tag-vlan)##
Tag based vlan Added Successfully.
Vlan id :10
Vlan name : engineering
Ports :3-5
ML1200(tag-vlan)##
Tag based vlan edited Successfully.
Vlan id : 10
Vlan name : engineering
Ports : 3-5
ML1200(tag-vlan)##
Tag based vlan Added Successfully.
Vlan id :20
Vlan name : sales
Ports :3-5
ML1200(tag-vlan)##
ERROR: Duplicate Vlan Id
ML1200(tag-vlan)##
Tag based vlan Added Successfully.
Vlan id :30
Vlan name : marketing
Ports :3-5
ML1200(tag-vlan)##
(continued on next page)
MULTILINK ML1200 MANAGED FIELD SWITCH – INSTRUCTION MANUAL
| STATUS
UP
DOWN
DOWN
DOWN
DOWN
DOWN
UP
add id=10 name=mkt port=3-5
edit id=10 name=engineering port=3-5
add id=20 name=sales port=3-5
add id=20 name=marketing port=3-5
add id=30 name=marketing port=3-5
show vlan type=tag
Note that ports 3 to 5 are "DOWN" - the
VLAN configuration is preferably done
before devices are plugged in to avoid
connectivity repercussions.
Intentionally executed to
show the effect of adding a
duplicate VLAN.
VLAN
10–15
