GE MultiLink ML1200 Instruction Manual page 63

CHAPTER 4: OPERATION
H4, HH 1000 Mb FX
(Gigabit)
H5, HI 1000 Mb FX
(Gigabit)
H6, HJ 1000 Mb FX
(Gigabit)
Note
MULTILINK ML1200 MANAGED FIELD SWITCH – INSTRUCTION MANUAL
Single-Mode 25 1310
Single-Mode 40 1550
Single-Mode 70 1550
* The use of either multi-mode or single-mode fiber to operate at 100Mbps speed over
long distances (i.e., in excess of approx. 400 meters) can be achieved only if the following
factors are both applied:
• The 100Mb fiber segment must operate in full-duplex (FDX) mode, i.e. the full-
duplex (factory default) setting for 100Mbps fiber ports must be used, and
• The worst-case OPB of the fiber link must be greater than the fiber cable's passive
Attenuation.
(Attenuation = Cable loss + LED aging loss + Insertion loss + safety factor)
9/125 -3.0 -21
9/125 -5.0 -22
9/125 -2.0 -22
OPERATION
16 40 18 45
15 60 17 68
18 90 20 100
4–5
