SPANNING TREE PROTOCOL (STP)
Example 12-3: Enabling STP
show active-stp
ML1200#
Current Active Mode: RSTP.
RSTP is Disabled.
stp
ML1200#
ERROR: Invalid Command
set stp type=stp
ML1200#
STP Mode set to STP.
stp
ML1200#
stp enable
ML1200(stp)##
Successfully set the STP status
show stp config
ML1200(stp)##
STP CONFIGURATION
-----------------
Spanning Tree Enabled(Global) :
Spanning Tree Enabled(Ports)
Protocol
Bridge ID
Bridge Priority
Bridge Forward Delay
Bridge Hello Time
Bridge Max Age
Root Port
Root Path Cost
Designated Root
Designated Root Priority
Root Bridge Forward Delay
12–6
Example 12-3 shows how to enable STP using the above commands.
The command specifies the port or switch level priority. When a port(s) are
priority
specified the priority is associated with ports and their value is 0 to 255. If no ports are
specified, then the switch (bridge) priority is specified and its value is 0 to 65535. This value
is used along with the switch MAC address to determine which switch in the network is the
root device. Lower values mean higher priority. The default value is 32768.
YES
: YES, 1,2,3,4,5,6,7
: Normal STP
: 80:00:00:20:06:2b:e1:54
: 32768
: 15
: 2
: 20
: 0
: 0
: 80:00:00:20:06:2b:e1:54
: 32768
: 15
