GE MultiLink ML1200 Instruction Manual page 35

CHAPTER 1: INTRODUCTION
MULTILINK ML1200 MANAGED FIELD SWITCH – INSTRUCTION MANUAL
Reboot the switch when the transfer is complete.
After reboot, the firmware is ready for use.
If using TFTP, save the configuration before proceeding.
GE Multilin recommends a two-step update:
• first save the configuration to the TFTP server,
• then load the new image and restart the switch (refer to section
5.4.4 - Saving Configuration for details on saving the
configuration).
Load the new firmware as shown below.
As the file is being loaded, the firmware will display the transfer in progress window.
Reboot the switch when the transfer is complete.
After reboot, the firmware is ready for use.
INTRODUCTION
1–27
